Display

Panel Size

21.5" ( 16:9 )

Resolution

1920 x 1080  ( FHD )

Display Brightness

400 cd/m2

Contrast Ratio

1000:1

Backlight Lifetime

50000 Hr (min.)

Viewing Angle

89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D )

Touch screen

Touch Type

10 point PCAP

Surface Hardness

≥7H

I / O

VGA

1 x VGA

H-DMI

1 x H-DMI

USB

1 x Touch  USB

Other I/O Interface

1 x OSD Control Key

Button

RAFI FS22+ Select / Green / Red / Stop Button ( optional )

Bracket kit

Stainless Steel 48 Series

Power

Power Adapter

1 x Optional AC/DC 12V/4A , 48W

Power Input

2-pin Terminal Block Connector with Power Input 12~24VDC

Power Consumption

≦30W

Physical

Material

Aluminum alloy panel, anodized treatment

Mounting

Stand / Wall / VESA / Panel

Dimension (W x H x D）

538 x 395 x 135 mm

Packing Size

930 x 230 x 610 mm

Weight (Net)

12 kg

Environment

Operating Temperature

-20~70°C  ( -4~158°F )

Storage Temperature

-30~80°C (-22~176°F)

Relative Humidity

5%~95%@40°C, non-condensing

Vibration Protection

1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

IP Level

Front Panel IP66

EMC

CE, FCC，ROHS

ORDERING INFORMATION

AVAILABLE MODELS

DESCRIPTION

DCM-H215WAC

21.5” FHD LED / Resolution 1920x1080 / PCAP Touch / VGA / H-DMI / T-USB / DC 12~24V

PACKING LIST

1x 21.5”Device control Monitor

1x 1.5m H-DMI Cable

1x 1.5m T-USB Cable

Bracket kit: Stainless Steel 48 Series

1x Power Adaptor
