WPC-15SDC-12th
Product features：
- Industrial-grade 15" XGA LCD panel with 50k backlight lifetime
- Optical bonding PCAP multipoint touch screen
- 12th Gen Intel® Alder Lake Core™ i3 / i5 processor
- 2 x DDR5 SDRAM, max.64GB, 1 x M.2 2280 NVMe or SATA SSD
- M12 I/O ports：2 x LAN / 2 x USB / 1 x COM
- Full device IP66/IP69K with Stainless Steel SUS304/316 construction
- Support TPM2.0 hardware security
- Wide Operating Temperature -20°C to 70°
- 9V to 36V DC Wide Range Power Input，Supporting OVP / OCP / RPP
|
System |
||
|
CPU |
12th Gen Intel® Alder Lake Core™ i3-1215U 1.2GHz |
12th Gen Intel® Alder Lake Core™ i5-1235U 1.3GHz |
|
TDP |
15W |
15W |
|
L3 Cache |
10MB |
12MB |
|
Graphics |
Intel® UHD Graphics |
Intel® Iris® Xe Graphics |
|
System Chipset |
Integrated with Intel® SoC |
|
|
Memory |
2 x DDR5 4800 MHz 8GB, Up to 64GB |
|
|
Harddisk |
1 x M.2 128G SSD ( 250G / 500G / 2TB SSD ) |
|
|
Network |
Intel® 226-V GbE LAN |
|
|
Audio |
Realtek ALC897 Audio controller |
|
|
TPM |
TPM 2.0 |
|
|
Watchdog Timer |
Software Programmable Supports 1~255 sec. System Reset |
|
|
Operation System |
Windows 10 / 11， Linux, Ubuntu |
|
|
I/O |
||
|
VIDEO |
1 x H-DMI ( Optional ) |
|
|
Ethernet |
2 x M12 Waterproof Giga LAN RJ45 Connector |
|
|
USB |
2 x M12 Waterproof Connector For USB2.0 |
|
|
COM |
1 x M12 Waterproof Connector For COM |
|
|
Wireless Network |
Optional ( WiFi / Bluetooth / 4G / 5G ) |
|
|
Other I/O Interface |
1 x Power Switch |
|
|
Expansion |
||
|
M.2 |
1*M.2 ( Key-E, 2230, PCIe+USB, Wifi+BT) |
|
|
1*M.2 ( Key-B, 3042/3052, PCIe/ USB 3.0+USB2.0, 4G/5G ) |
||
|
1*M.2 ( Key-M, 2280, NVMe / SATA, SSD ) |
||
|
SIM Socket |
1x SIM Socket |
|
|
Display |
||
|
LCD Size |
15" ( 4:3 ) |
|
|
Resolution |
1024 x 768 |
|
|
Brightness (cd/m²) |
350 cd/m2 |
|
|
Contrast Ratio |
1000:1 |
|
|
Backlight MTBF |
50,000 hrs ( LED Backlight ) |
|
|
Viewing Angle |
89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D ) |
|
|
Touch screen |
||
|
Touch Type |
Optical bonding PCAP Touch |
|
|
Surface Hardness |
≥7H |
|
|
Power |
||
|
Power Adapter |
1 x M12 Waterproof Connector For 9V~36V DC |
|
|
Power Mode |
Support AT, ATX Mode |
|
|
Power Protection |
OVP (Over Voltage Protection) | OCP (Over Current Protection) | RPP（Reverse Polarity Protection） |
|
|
Power Consumption |
≦45W |
|
|
Physical |
||
|
Material |
Inox / SUS304 / SUS316 ( Optional ) |
|
|
Mounting |
Stand / Wall / VESA / Yoke |
|
|
Dimension (W x H x D） |
359 x 283 x 45 mm |
|
|
Packing Size |
460 x 180 x 400 mm |
|
|
Weight (Net) |
6.5 KG |
|
|
Environment |
||
|
Operating Temperature |
-20~70°C ( -4~158°F ) |
|
|
Storage Temperature |
-30~80°C (-22~176°F) |
|
|
Relative Humidity |
5%~95%@40°C, non-condensing |
|
|
Vibration Protection |
1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis |
|
|
IP Level |
IP66 / IP69K |
|
|
EMC |
CE, FCC，Class A，ROHS |
|
|
ORDERING INFORMATION |
|
|
AVAILABLE MODELS |
DESCRIPTION |
|
WPC-3015SDC |
15" XGA LCD / Resolution 1024 x 768 / 12th Gen Intel® Alder Lake Core™ i3-1215U 1.2GHz / Optical bonding PCAP Touch / 2 x LAN / 1 x COM / 2 x USB / TPM2.0 / DC IN 9V~36V (OVP / OCP / RPP) |
|
WPC-5015SDC |
15" XGA LCD / Resolution 1024 x 768 / 12th Gen Intel® Alder Lake Core™ i5-1235U 1.3GHz / Optical bonding PCAP Touch / 2 x LAN / 1 x COM / 2 x USB / TPM2.0 / DC IN 9V~36V (OVP / OCP / RPP) |
|
|
|
|
CONFIGURATION |
DESCRIPTION |
|
Memory |
RAM：DDR5 4800 MHz 8GB, Up to 64GB |
|
Harddisk |
M.2 / 2.5" SATA SSD：120G/250G/500G/2TB |
|
WiFi |
Wi-Fi Bluetooth Combo Module, with antenna |
|
4G/5G |
Full Netcom 4G/5G/LTE module, with antenna |
|
|
|
|
PACKING LIST |
|
|
15" Stainless Steel PC |
|
|
1 x 60W PSU (Power Supply) |
|
|
2 x M12 Waterproof LAN Cable 2M |
|
|
2 x M12 Waterproof USB Cable 2M |
|
|
1 x M12 Waterproof COM Cable 2M |
|
|
1 x CD-ROM |
|
