System

CPU

Intel® Skylake Core i5-6200U Dual Core 2.3GHz

L2 Cache

3.0MB

TDP

15W

System Chipset

Integrated with Intel® SoC

Memory

1 x DDR4L 2133MHz 4GB, Up to 16GB

Harddisk

1 x mSATA 128G SSD / (250G / 500G / 1TB SSD)  / 1 x 2.5" SATA

Graphics

Intel HD Graphics 520

Network

Intel® I211-AT GbE LAN

Audio

Realtek ACL662 Audio controller

Operation System

Windows 7 / 8 / 10 ，Linux, Ubuntu

I/O

VIDEO

1 x H-DMI

Ethernet

2 x M12 Waterproof Giga LAN RJ45 Connector

USB

2 x M12 Waterproof Connector For USB2.0

COM

1 x M12 Waterproof Connector For COM

Wireless Network

Optional （WiFi / Bluetooth / 4G / 5G )

Other I/O Interface

1 x Power Switch

Expansion

mPCe

1 x mPCe ( PCIe+USB, Wifi+BT+4G)

SIM Socket

1x SIM Socket

Power

Power Adapter

1 x Optional AC/DC 12V/5A , 60W

Power Input

2-Pin M12 Power Input 12~24VDC

Power Consumption

≦35W

Physical

Material

Aluminum Alloy Shell

Color

Grey / Silver / Black ( optional )

Product Dimension

220 x 180 x 55 mm

Mounting

232 x 90 mm / 100 x 100 mm

Packing Size

360 x 180 x 320 mm

Weight (Net)

1.5 KG

Environment

Operating Temperature

-30~70°C  ( -22~158°F )

Storage Temperature

-40~85°C (-40~185°F)

Relative Humidity

5%~95%@40°C, non-condensing

Vibration Protection

1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

IP Level

IP67 / IP69K

EMC

CE, FCC，Class A，ROHS

ORDERING INFORMATION

AVAILABLE MODELS

DESCRIPTION

EFIC-6000PA

Intel® Skylake Core i5-6200U 2.3GHz / 1 x HDMI / 2 x LAN / 2 x USB2.0 / 1 x COM / TPM2.0 / DC 12V~24V Wide Range Power Input

CONFIGURATION

DESCRIPTION

Memory

RAM：DDR4L 2133MHz 4GB, Up to 16GB

Harddisk

mSATA 128G SSD / (250G / 500G / 1TB SSD) 1 x 2.5" SATA

WiFi

Wifi Bluetooth Combo Module, with antenna

4G

Full Netcom 4G/LTE module, with antenna

PACKING LIST

1 x Standard product

1 x 60W PSU (Power Supply)

1 x Fixed support

2 x M12 Waterproof USB Cable 2M

1 x M12 Waterproof COM Cable 2M

2 x M12 Waterproof LAN Cable 2M

1 x Waterproof HDMI Cable 2M

1 x CD-ROM
