System

CPU

Intel® Core i3-8145U 2.1GHz / i5-8265U 1.6GHz / i7-8565U 1.8GHz, TDP 25W

L2 Cache

4MB / 6MB / 8MB

System Chipset

Integrated with Intel® SoC

Memory

DDR4L 2400MHz 4GB, Up to 64GB

Harddisk

1 x M.2 120G SSD ( 250G / 500G / 2TB SSD) / 1 x 2.5" SATA

Graphics

Intel® HD Graphics 620

Network

Intel® I211-AT GbE LAN

Audio

Realtek ACL662 Audio controller

TPM

TPM 2.0

Watchdog Timer

Software Programmable Supports 1~255 sec. System Reset

Operation System

Windows 10 / 11， Linux, Ubuntu

I/O

VIDEO

1 x H-DMI

LAN

2 x LAN （10/100/1000 Mbps）

USB

1 x USB 2.0 / 3 x USB 3.0

COM

2 x RS-232 / 422 / 485

Audio

1x Audio_out & Mic_in

Wireless Network

Optional（WiFi / Bluetooth / 4G / 5G )

Display

LCD Size

10.4" ( 4:3 )

Resolution

800 x 600 / 1024 x 768 (Optional)

Brightness (cd/m²)

350 cd/m2

Contrast Ratio

800:1

Backlight MTBF

30000 Hr (min.)

Viewing Angle

80 / 80 / 65 / 75 (CR≥10) ( L / R / U / D )

Touch screen

Touch Type

5 Wire Resistive touch

Surface Hardness

≥3H

Power

Power Adapter

1 x Optional AC/DC 12V/5A ，60W

Power Mode

Support AT, ATX Mode

Power Input

2-pin Terminal Block Connector with Power Input 9~36VDC

Power Protection

OVP (Over Voltage Protection) / OCP (Over Current Protection) / RPP（Reverse Polarity  Protection）

Power Consumption

≦30W

Physical

Material

Aluminum alloy panel, anodized treatment

Mounting

Stand / Wall / VESA / Panel

Dimension (W x H x D）

275 x 222 x 60 mm

Cut-out Size

263 x 210 mm

Packing Size

360 x 180 x 320 mm

Weight (Net)

2.8 KG

Environment

Operating Temperature

-20~70°C  ( -4~158°F )

Storage Temperature

-30~80°C (-22~176°F)

Relative Humidity

5%~95%@40°C, non-condensing

Vibration Protection

1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

IP Level

Front Panel IP65

EMC

CE, FCC，ROHS

ORDERING INFORMATION

AVAILABLE MODELS

DESCRIPTION

PPC-3010SAR

10.4” TFT LCD / Resolution 800x600 / 1024x768(Optional) / Resistive Touch / Intel Core i3-8145U 2.1GHz / 2x Intel®I211 GbE LAN / 2xCOM(RS232 / 422 / 485) 3xUSB3.0 / 1xUSB2.0 / TPM2.0 / DC 9~36V (OVP / OCP / RPP)

PPC-5010SAR

10.4” TFT LCD / Resolution 800x600 / 1024x768(Optional) / Resistive Touch / Intel Core i5-10210U 1.6GHz / 2x Intel®I211 GbE LAN / 2xCOM(RS232 / 422 / 485) 3xUSB3.0 / 1xUSB2.0 / TPM2.0 / DC 9~36V (OVP / OCP / RPP)

PPC-7010SAR

10.4” TFT LCD / Resolution 800x600 / 1024x768(Optional) / Resistive Touch / Intel Core i7-8565U 1.8GHz / 2x Intel®I211 GbE LAN / 2xCOM(RS232 / 422 / 485) 3xUSB3.0 / 1xUSB2.0 / TPM2.0 / DC 9~36V (OVP / OCP / RPP)

CONFIGURATION

DESCRIPTION

Memory

RAM：DDR4L 2400MHz SO-DIMM.4GB/64GB

Harddisk

M.2/2.5" SATA SSD：120G/250G/500G/2TB

WiFi

Wi-Fi Bluetooth Combo Module, with antenna

4G/5G

Full Netcom 4G/5G/LTE module, with antenna

PACKING LIST

1x 10.4” Industrial Panel PC

1x  CD-ROM

8x  Embedded Buckles

1x  Power Adaptor
