DCP-215WAC
Product features:
- Industrial-grade 21.5" FHD LCD panel with 50k backlight lifetime
- True-flat touchscreen with multi-touch projected capacitive control
- IP66 grade aluminum alloy front panel
- 12th Gen Intel® Alder Lake Core™ i3 / i5 / i7 processor
- 2 x DDR5 SDRAM, max.64GB, 1*M.2 2280 NVMe or SATA SSD
- 2 x Intel® 226-V 2.5GbE / 1 x Intel® 219 GbE, support WoL and PXE
- Supports TPM2.0 security encryption and vPro technology
- Support RAFIFS22+ series button expansion and stainless steel 48series
- Wide Operating Temperature -20°C to 70°C
- 9V to 36V DC Wide Range Power Input,Supporting OVP / OCP / RPP
![CE](/Data/logo/625e28bef2858.png)
![RoHS](/Data/logo/625e289f83fb2.png)
![FC](/Data/logo/625e28b65e7c8.png)
![TPM](/Data/logo/625e28cf54315.png)
![IP66](/Data/logo/625e28e51f0c7.png)
![](/Data/editor/66583174b9ad2.jpg)
System |
|||
CPU |
12th Gen Intel® Alder Lake Core™ i3-1215U 1.2GHz |
12th Gen Intel® Alder Lake Core™ i5-1235U 1.3GHz |
12th Gen Intel® Alder Lake Core™ i7-1255U 1.7GHz |
TDP |
15W |
15W |
15W |
L3 Cache |
10MB |
12MB |
12MB |
Graphics |
Intel® UHD Graphics |
Intel® Iris® Xe Graphics |
Intel® Iris® Xe Graphics |
System Chipset |
Integrated with Intel® SoC |
||
Memory |
DDR5 4800 MHz, Dual Channel SODIMM x 2, up to 64GB |
||
Harddisk |
1 x M.2 120G SSD ( 250G / 500G / 2TB SSD) / 1 x 2.5" SATA |
||
Network |
Intel® 226-V / I219-LM GbE LAN |
||
Audio |
Realtek ACL897 Audio controller |
||
TPM |
TPM 2.0 |
||
Watchdog Timer |
Software Programmable Supports 1~255 sec. System Reset |
||
Operation System |
Windows 10 / 11, Linux, Ubuntu |
||
I/O |
|||
VIDEO |
2 x HD-MI |
||
Ethernet |
2 x 2.5GbE / 1x 1GbE |
||
USB |
4 x USB 3.2 Gen2 |
||
Button |
RAFI FS22+ Select / Green / Red / Stop Button ( optional ) |
||
Bracket kit |
Stainless Steel 48 Series |
||
Wireless Network |
Optional ( WiFi / Bluetooth / 4G / 5G ) |
||
Expansion |
|||
M.2 |
1*M.2 ( Key-E, 2230, PCIe+USB, Wifi+BT ) |
||
1*M.2 ( Key-B, 3042/3052, PCIe/ USB 3.0+USB2.0, 4G/5G ) |
|||
1*M.2 ( Key-M, 2280, NVMe/ SATA, SSD ) |
|||
SIM Socket |
1x SIM Socket |
||
Display |
|||
LCD Size |
21.5" ( 16:9 ) |
||
Resolution |
1920 x 1080 ( FHD ) |
||
Brightness (cd/m²) |
400 cd/m2 |
||
Contrast Ratio |
1000:1 |
||
Backlight MTBF |
50000 hrs |
||
Viewing Angle |
89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D ) |
||
Touch screen |
|||
Touch Type |
10 point PCAP |
||
Surface Hardness |
≥7H |
||
Power |
|||
Power Adapter |
1 x Optional AC/DC 12V/5A , 60W |
||
Power Mode |
Support AT, ATX Mode |
||
Power Input |
2-pin Terminal Block Connector with Power Input 9~36VDC |
||
Power Protection |
OVP (Over Voltage Protection) | OCP (Over Current Protection) | RPP(Reverse Polarity Protection) |
||
Power Consumption |
≦45W |
||
Physical |
|||
Material |
Aluminum alloy panel, anodized treatment |
||
Mounting |
Stand / Wall / VESA |
||
Dimension (W x H x D) |
538 x 395 x 135 mm |
||
Cut-out Size |
/ |
||
Packing Size |
930 x 230 x 610 mm |
||
Weight (Net) |
12.5 KG |
||
Environment |
|||
Operating Temperature |
-20~70°C ( -4~158°F ) |
||
Storage Temperature |
-30~80°C (-22~176°F) |
||
Relative Humidity |
5%~95%@40°C, non-condensing |
||
Vibration Protection |
1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis |
||
IP Level |
Front Panel IP66 |
||
EMC |
CE, FCC,KC ,Class A,ROHS ,IEC / EN 62368-1 |
ORDERING INFORMATION |
|
AVAILABLE MODELS |
DESCRIPTION |
DCP-3215WAC |
21.5" FHD LCD / Resolution 1920 x 1080 / 12th Gen Intel® Alder Lake Core™ i3-1215U 1.2GHz / PCAP touch / 2 x HD-MI / 2 x 2.5GbE / 1x 1GbE / 4 x USB 3.2 Gen2 / RAFI FS22+ Select / Green / Red / Stop Button ( optional ) / TPM2.0 / DC IN 9V~36V (OVP / OCP / RPP) |
DCP-5215WAC |
21.5" FHD LCD / Resolution 1920 x 1080 / 12th Gen Intel® Alder Lake Core™ i5-1235U 1.3GHz / PCAP touch / 2 x HD-MI / 2 x 2.5GbE / 1x 1GbE / 4 x USB 3.2 Gen2 / RAFI FS22+ Select / Green / Red / Stop Button ( optional ) / TPM2.0 / DC IN 9V~36V (OVP / OCP / RPP) |
DCP-7215WAC |
21.5" FHD LCD / Resolution 1920 x 1080 / 12th Gen Intel® Alder Lake Core™ i7-1255U 1.7GHz / PCAP touch / 2 x HD-MI / 2 x 2.5GbE / 1x 1GbE / 4 x USB 3.2 Gen2 / RAFI FS22+ Select / Green / Red / Stop Button ( optional ) / TPM2.0 / DC IN 9V~36V (OVP / OCP / RPP) |
|
|
CONFIGURATION |
DESCRIPTION |
Memory |
RAM:DDR5 4800 MHz, Dual Channel SODIMM x 2, up to 64GB |
Harddisk |
M.2 / 2.5" SATA SSD:120G/250G/500G/2TB |
WiFi |
Wi-Fi Bluetooth Combo Module, with antenna |
4G/5G |
Full Netcom 4G/5G/LTE module, with antenna |
|
|
PACKING LIST |
|
1 x Standard product |
|
1 x 60W PSU (Power Supply) |
|
1 x CD-ROM |
|
1 x Power cable & plug |
