WPC-J215WAC
Product features：
- Aluminium Alloy Shell, Whole PC IP66/IP69K Waterproof
- 21.5" TFT LED, Resolution 1920x1080, PCAP Touch
- Intel Celeron J1900 CPU:2.0GHz, Waterproof PC
- Multi Ports For Optional, VGA/LAN/USB/COM
- DC12V~24V Input
|
System |
|
|
CPU |
Intel Celeron J1900 2.0GHz |
|
L2 Cache |
2MB |
|
Chipsets |
Intel Bay Trail SOC |
|
Memory |
DDR3L 1333MHz 4GB, Up to 8GB |
|
Harddisk |
1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional |
|
Graphics |
Intel HD Graphics |
|
Network |
Intel 82583V 1000 Mbps port |
|
Audio |
Realtek ACL662 Audio controller |
|
Operation System |
Windows 7 / 8 / 10, Linux, Unix, QNX |
|
I/O |
|
|
VGA |
1 x VGA / 1 x HD-MI ( Optional ) |
|
LAN |
1 x LAN ( Optional ) |
|
USB |
3 x USB2.0 / 1 xUSB3.0 ( Optional ) |
|
COM |
2 x RS232 ( Optional ) |
|
Wifi |
WiFi + Bluetooth ( Optional ) |
|
Other I/O Interface |
1 x Power Switch |
|
LCD Panel |
|
|
Panel Size |
21.5" Led |
|
Resolution |
1920 x 1080 |
|
Aspect Ratio |
16:9 |
|
Display Brightness |
250 cd/m2 |
|
Contrast Ratio |
3000:1 |
|
Colors |
16.7M, 74%NTSC |
|
Backlight Lifetime |
13/5 (Typ.)(Tr/Td) ms |
|
Viewing Angle |
89 / 89 / 89 / 89 (CR≥10) ( L / R / U / D ) |
|
Touch screen |
|
|
Touch Screen Type |
Capacitive Touch |
|
Transmittance |
>90% |
|
Response Time |
<5ms |
|
Surface Hardness |
≥6H |
|
Supply Voltage |
5.0V DC |
|
Touch Life |
≧3000W |
|
Institutional |
|
|
Material |
Aluminum Alloy Shell |
|
Color |
Silver / Black ( optional ) |
|
VESA Mounting |
VESA: 100 x 100 mm |
|
Waterproof Rate |
IP66 / IP69K |
|
Product Dimension |
536 x 328 x 40 mm |
|
Cut-out Size |
/ |
|
Packing Size |
630 x 190 x 480 mm |
|
Gross Weight |
12.0 KG |
|
Power and Environment |
|
|
Operating Temperature |
-10~60°C |
|
Storage Temperature |
-20~80°C(-22~176°F) |
|
Relative Humidity |
5%~95%@40°C, non-condensing |
|
Vibration Range |
5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
|
External Power Supply |
AC 100 - 240V~50/60Hz,1.5A |
|
Working Voltage |
DC 12V~24V / Optional(+9V~36V) |
|
Power Consumption |
≦30W |
|
ORDERING INFORMATION |
|
|
AVAILABLE MODELS |
DESCRIPTION |
|
WPC-J215WAC |
21.5” TFT LED / Resolution 1920x1080 / Intel Celeron J1900 2.0GHz / PCAP Touch / VGA / LAN / COM / USB / DC IN 12V~24V |
|
|
|
|
CONFIGURATION |
DESCRIPTION |
|
Memory |
RAM：DDR3L 1333MHz SO-DIMM.4GB/8GB |
|
Harddisk |
mSATA SSD：32G/64G/120G/250G/500G |
|
WiFi |
Wi-Fi Bluetooth Combo Module, with antenna |
|
|
|
|
PACKING LIST |
|
|
1x 21.5” Waterproof Industrial PC |
|
|
1x CD-ROM |
|
|
1x 1.5m I/O Cable |
|
|
1x Power Adaptor |
|
